40x40X20mm 5V 12V 24VDC Cooling Blower
Product Attributes
l Size / Dimension: 40x40X20mm
l Voltage - Rated：5VDC / 12VDC / 24VDC
l Bearing Type: Sleeve / Hydraulic / Ball Bearing
l Air Flow: 0.057 ~ 0.113m³/min（2.00 ~ 4.00 CFM）
l Static Pressure: 2.64 ~ 12.16 mm H2O（0.104 ~ 0.479 in H2O）
l Noise: ＜27.4 ~ 44.5 dB(A)
l RPM: 4500 / 8500 RPM
l Current Rating (Amps): 0.03 ~ 0.38A
l Voltage Range: 1.8 ~ 3 ~ 6VDC / 7 ~ 13.5VDC / 18 ~ 26.5VDC
l Material - Frame: Plastic (Flammability: UL94V-0)
l Material - Blade: Plastic (Flammability: UL94V-0)
l Power (Watts)：0.72 ~ 2.16W
l Weight: 29g
Certifications:
CE & FCC Listed
REACH Compliant
Model
Rated Voltage
Operating Voltage Range
Rated Current
Rated
Input Power
Speed
Maximum Air Flow
Maximum Air Pressure
Noise
PART.NO.
VDC
VDC
Amp
Watt
R.P.M
M³/min
CFM
mmH2O
InH2O
dB-A
CLB4020LL05X
5
1.8~3~6
0.14
0.72
4500
0.057
2.00
2.64
0.104
27.4
CLB4020L05X
5
1.8~3~6
0.16
0.8
5000
0.064
2.27
3.35
0.132
30.2
CLB4020ML05X
5
1.8~3~6
0.24
1.2
5500
0.073
2.56
4.18
0.165
33.5
CLB4020LM05X
5
1.8~3~6
0.29
1.44
6000
0.078
2.75
5.22
0.206
35.7
CLB4020M05X
5
1.8~3~6
0.34
1.68
6500
0.087
3.06
6.55
0.258
37.4
CLB4020H05X
5
1.8~3~6
0.38
1.92
7500
0.100
3.54
9.13
0.359
40.9
CLB4020LL12X
12
7~13.5
0.06
0.72
4500
0.057
2.00
2.64
0.104
27.4
CLB4020L12X
12
7~13.5
0.07
0.8
5000
0.064
2.27
3.35
0.132
30.2
CLB4020ML12X
12
7~13.5
0.1
1.2
5500
0.073
2.56
4.18
0.165
33.5
CLB4020LM12X
12
7~13.5
0.12
1.44
6000
0.078
2.75
5.22
0.206
35.7
CLB4020M12X
12
7~13.5
0.14
1.68
6500
0.087
3.06
6.55
0.258
37.4
CLB4020H12X
12
7~13.5
0.16
1.92
7500
0.100
3.54
9.13
0.359
40.9
CLB4020HH12X
12
7~13.5
0.18
2.16
8500
0.113
4.00
12.16
0.479
44.5
CLB4020LL24X
24
18~26.5
0.03
0.72
4500
0.057
2.00
2.64
0.104
27.4
CLB4020ML24X
24
18~26.5
0.05
1.2
5500
0.073
2.56
4.18
0.165
33.5
CLB4020LM24X
24
18~26.5
0.06
1.44
6000
0.078
2.75
5.22
0.206
35.7
CLB4020M24X
24
18~26.5
0.07
1.68
6500
0.087
3.06
6.55
0.258
37.4
CLB4020H24X
24
18~26.5
0.08
1.92
7500
0.100
3.54
9.13
0.359
40.9
CLB4020HH24X
24
18~26.5
0.09
2.16
8500
0.113
4.00
12.16
0.479
44.5
