DC Axial Fan

  • 3010B 5V 12VDC (30X30X10mm) Cooling Fan
  • 3010B 5V 12VDC (30X30X10mm) Cooling Fan
  • 3010B 5V 12VDC (30X30X10mm) Cooling Fan
  • 3010B 5V 12VDC (30X30X10mm) Cooling Fan
3010B 5V 12VDC (30X30X10mm) Cooling Fan3010B 5V 12VDC (30X30X10mm) Cooling Fan3010B 5V 12VDC (30X30X10mm) Cooling Fan3010B 5V 12VDC (30X30X10mm) Cooling Fan

3010B 5V 12VDC (30X30X10mm) Cooling Fan

  • Product description: 3010B - 30X30X10mm 5V 12VDC Axial Fan Sleeve/Hydraulic/Ball Bearing 0.12m³/min 4.25CFM - DC brushless axial fans and quiet cooling solutions from Cooling Technology.
  • INQUIRY

3010B - 30x30x10mm 5V 12VDC Cooling Fan


Product Attributes

      l Size / Dimension: 30x30x10mm
l Voltage - Rated5VDC / 12VDC
l Bearing Type: Sleeve / Hydraulic / Ball Bearing
l Air Flow: 0.028 ~ 0.12 m³/min(0.98 ~ 4.25 CFM
l Static Pressure: 1.22 ~ 8.25 mm H2O(0.048 ~ 0.325 in H2O
l Noise: 15.5 / 34.9 dB(A)
l RPM: 5000 ~ 13000 RPM
l Current Rating (Amps): 0.06 ~ 0.24A
l Voltage Range: 1.8 ~ 3 ~6VDC / 8.5 ~ 13.5VDC
l Material - Frame: Plastic (Flammability: UL94V-0)
l Material - Blade: Plastic (Flammability: UL94V-0)
l Power (Watts)0.72 ~ 1.2 W
l Weight: 8g

Certifications:

CE Listed

FCC Listed

REACH Compliant


Model Rated Voltage Operating Voltage Range Rated Current
Rated
Input Power
Speed Maximum Air Flow Maximum Air Pressure Noise
PART.NO. VDC VDC Amp Watt R.P.M M³/min CFM mmH2O InH2O dB-A
CLD3010L05X 5 1.8~3~6 0.14 0.72 5000 0.028 0.98 1.22 0.048 15.5
CLD3010M05X 5 1.8~3~6 0.17 0.84 7000 0.064 2.25 2.50 0.098 22.4
CLD3010H05X 5 1.8~3~6 0.19 0.96 9000 0.084 2.95 4.25 0.167 26.3
CLD3010HH05X 5 1.8~3~6 0.22 1.08 11000 0.102 3.61 6.28 0.247 32.0
CLD3010VH05X 5 1.8~3~6 0.24 1.2 13000 0.120 4.25 8.25 0.325 34.9
CLD3010L12X 12 8.5~13.5 0.06 0.72 5000 0.028 0.98 1.22 0.048 15.5
CLD3010M12X 12 8.5~13.5 0.07 0.84 7000 0.064 2.25 2.50 0.098 22.4
CLD3010H12X 12 8.5~13.5 0.08 0.96 9000 0.084 2.95 4.25 0.167 26.3
CLD3010HH12X 12 8.5~13.5 0.09 1.08 11000 0.102 3.61 6.28 0.247 32.0
CLD3010VH12X 12 8.5~13.5 0.1 1.2 13000 0.120 4.25 8.25 0.325 34.9
