  • Product description: 6015 - Axial Fan 60X60X15mm 5V 12V 24VDC Sleeve/Hydraulic/Dual Ball Bearing 0.603m³/min 21.1CFM - DC Brushless fan and quiet cooling solutions from Cooling Technology.
  • INQUIRY

60x60x15mm 5V 12V 24VDC Cooling Fan


Product Attributes

Size / Dimension: 60x60x15mm

Voltage - Rated5VDC / 12VDC / 24VDC

Bearing Type: Sleeve / Hydraulic / Dual Ball Bearing

Air Flow: 0.268 ~ 0.603 m³/min(9.41 ~ 21.1 CFM

Static Pressure: 1.34 ~ 7.33 mm H2O(0.053 ~ 0.289 in H2O

Noise: 21.1 / 41.0 dB(A)

RPM: 2000 ~ 6000 RPM

Current Rating (Amps): 0.03 ~ 0.2A

Voltage Range: 1.8 ~ 3 ~ 6VDC / 7 ~ 13.5VDC / 18 ~ 26.5VDC

Material - Frame: Plastic (Flammability: UL94V-0)

Material - Blade: Plastic (Flammability: UL94V-0)

Power (Watts)0.72 ~ 2.4 W

Weight: 38g



Certifications:

CE Listed

FCC Listed

REACH Compliant

Model Rated Voltage Operating Voltage Range Rated Current
Rated
Input Power
Speed Maximum Air Flow Maximum Air Pressure Noise
PART.NO. VDC VDC Amp Watt R.P.M M³/min CFM mmH2O InH2O dB-A
CLD6015L05X 5 1.8~3~6 0.14 0.72 2000 0.268 9.41 1.34 0.053 21.1
CLD6015M05X 5 1.8~3~6 0.19 0.96 3000 0.328 11.5 1.86 0.073 24.8
CLD6015ML05X 5 1.8~3~6 0.24 1.2 3500 0.406 14.2 2.61 0.103 29.8
CLD6015H05X 5 1.8~3~6 0.29 1.44 4000 0.468 16.4 3.5 0.138 31.2
CLD6015L12X 12 7~13.5 0.06 0.72 2000 0.268 9.41 1.34 0.053 21.1
CLD6015M12X 12 7~13.5 0.08 0.96 3000 0.328 11.5 1.86 0.073 24.8
CLD6015ML12X 12 7~13.5 0.1 1.2 3500 0.406 14.2 2.61 0.103 29.8
CLD6015H12X 12 7~13.5 0.12 1.44 4000 0.468 16.4 3.5 0.138 31.2
CLD6015HL12X 12 7~13.5 0.14 1.68 4500 0.524 18.3 4.35 0.171 34.8
CLD6015HH12X 12 7~13.5 0.16 1.92 5000 0.584 20.5 5.34 0.210 36.6
CLD6015HV12X 12 7~13.5 0.18 2.16 5500 0.640 22.4 6.35 0.25 39.0
CLD6015VH12X 12 7~13.5 0.2 2.4 6000 0.603 21.1 7.33 0.289 41.0
CLD6015L24X 24 18~26.5 0.03 0.72 2000 0.268 9.41 1.34 0.053 21.1
CLD6015M24X 24 18~26.5 0.04 0.96 3000 0.328 11.5 1.86 0.073 24.8
CLD6015ML24X 24 18~26.5 0.05 1.2 3500 0.406 14.2 2.61 0.103 29.8
CLD6015H24X 24 18~26.5 0.06 1.44 4000 0.468 16.4 3.5 0.138 31.2
CLD6015HL24X 24 18~26.5 0.07 1.68 4500 0.524 18.3 4.35 0.171 34.8
CLD6015HH24X 24 18~26.5 0.08 1.92 5000 0.584 20.5 5.34 0.210 36.6
CLD6015HV24X 24 18~26.5 0.09 2.16 5500 0.640 22.4 6.35 0.25 39.0
CLD6015VH24X 24 18~26.5 0.1 2.4 6000 0.603 21.1 7.33 0.289 41.0
